Description of Product
The exterior is constructed from cold-rolled steel sheet, while the working chamber is available in galvanized plate or stainless steel. Between the exterior and the chamber, aluminum silicate fiber wool and mineral wool board are filled as thermal insulation layers. A far-infrared heating radiator combined with an internal circulation blower ensures balanced air convection throughout the chamber.
Specification
TECHNICAL PARAMETERS
|
101-1A |
101-2A |
101-3A |
101-4 |
|
|
Standard drying temperature |
105℃ |
105℃ |
105℃ |
105℃ |
|
Temperature control accuracy |
≤2℃ |
≤2℃ |
≤2℃ |
≤2℃ |
|
Maximum temperature |
250℃ |
|||
|
Power supply |
AC220V/50Hz |
|||
|
Working chamber size |
350*450*450mm |
450*550*550mm |
500*600*750mm |
800*800*1000mm |
|
Working chamber material |
Galvanized plate |
Galvanized plate |
||
|
Heating power |
2.0KW |
3.0KW |
4.0KW |
6.0KW |
|
Dimensions |
710*550*710mm |
810*650*810mm |
860*700*1000mm |
1130*990*1300mm |
|
Weight |
45kg |
62kg |
70kg |
126kg |
Features
● The 304 stainless steel liner features ample thickness for durability and is easy to clean after each use.
● Equipped with a PT100 sensor and three-core high-temperature multi-strand shielded wire, ensuring strong anti-interference capability and high measurement precision.
● Utilizes solid state relays for spark-free operation, providing stable voltage and current during use.
● Constructed with heavy-duty high-quality alloy electric furnace wire, offering extended
