Zhuozhou Tianpeng Imp. and Exp. Trade Co., Ltd. is one of the leading manufacturers and suppliers of lab vacuum ovens in China. With abundant experience, we warmly welcome you to buy customized lab vacuum ovens made in China here from our factory. Quality products and reasonable price are available.
Description of Product
Vacuum ovens are highly versatile units widely used in laboratory research, engineering, and industrial applications. They are ideal for delicate drying processes, as the low-pressure environment helps minimize oxidation during drying.
Specification
TECHNICAL PARAMETERS
DZF6020
|
Performance |
|
|
Temperature range: ambient + 10°C to 200°C |
|
|
Maximal final vacuum pa: 100 |
|
|
Temperature fluctuation ±°C: < 0.1 |
|
|
Dimensions |
|
|
Working volume dm3: 20 |
Internal width mm: 300 |
|
Internal depth mm: 300 |
Internal height mm: 275 |
|
External width mm: 500 |
External depth mm: 450 |
|
External height mm: 790 |
|
|
Shelves in stainless steel |
|
|
Number standard: 1 |
Weight (empty) Kg: 45 |
|
Power supply 50 Hz 230 Volts (1) above 4000 watts: 400 V tri + T + N |
|
|
Maximum power Watts: 500 |
|
DZF6050
|
Performance |
|
|
Temperature range: ambient + 10°C to 200°C |
|
|
Maximal final vacuum pa: 100 |
|
|
Temperature fluctuation ±°C: < 0.1 |
|
|
Dimensions |
|
|
Working volume dm3: 50 |
Internal width mm: 415 |
|
Internal depth mm: 370 |
Internal height mm: 345 |
|
External width mm: 610 |
External depth mm: 510 |
|
External height mm: 850 |
|
|
Shelves in stainless steel |
|
|
Number standard: 2 |
Weight (empty) Kg: 70 |
|
Power supply 50 Hz 230 Volts (1) above 4000 watts: 400 V tri + T + N |
|
|
Maximum power Watts: 1400 |
|
DZF6052
|
Performance |
|
|
Temperature range: ambient + 10°C to 200°C |
|
|
Maximal final vacuum pa: 100 |
|
|
Temperature fluctuation ±°C: < 0.1 |
|
|
Dimensions |
|
|
Working volume dm3: 50 |
Internal width mm: 415 |
|
Internal depth mm: 370 |
Internal height mm: 345 |
|
External width mm: 610 |
External depth mm: 510 |
|
External height mm: 850 |
|
|
Shelves in stainless steel |
|
|
Number standard: 2 |
Weight (empty) Kg: 65 |
|
Power supply 50 Hz 230 Volts (1) above 4000 watts: 400 V tri + T + N |
|
DZF6090
|
Performance |
|
|
Temperature range: ambient + 10°C to 200°C |
|
|
Maximal final vacuum pa: 100 |
|
|
Temperature fluctuation ±°C: < 0.1 |
|
|
Dimensions |
|
|
Working volume dm3: 90 |
Internal width mm: 450 |
|
Internal depth mm: 450 |
Internal height mm: 450 |
|
External width mm: 660 |
External depth mm: 600 |
|
External height mm: 1500 |
|
|
Shelves in stainless steel |
|
|
Number standard: 2 |
Weight (empty) Kg: 175 |
|
Power supply 50 Hz 230 Volts (1) above 4000 watts: 400 V tri + T + N |
|
|
Maximum power Watts: 2800 |
|
Features
- Outer shell constructed using laser processing technology for precision and consistent quality
- Interior crafted from high-quality brushed stainless steel, offering excellent corrosion resistance and easy cleaning
- Heating element consists of a durable stainless steel heating tube for reliable and stable heat transfer
- Partition features a stainless steel baffle formed by laser molding, ensuring structural strength and flexible adjustment
- Electrical system includes leakage protector and solenoid valve for enhanced operational safety
- Temperature control system integrates PID control, timing, self-tuning, thyristor regulation, and LCD display for precise and stable temperature management
- Insulation layer made of high-quality aluminum silicate fiber wool with six-sided full insulation design to minimize heat loss
