Description of Product
The 16-T0013/B motor operated dynamic penetrometer is manufactured to Australian standards for soil penetration resistance testing. It measures underlying soil strength by recording penetration depth after each blow. The dropping height is adjustable between 600±5mm and 510±5mm, with a hammer weight of 9±0.1kg. The complete system includes a host unit, drive shaft, gasoline engine and manual extractor. The engine drives the lifting mechanism through a flexible shaft, raising the 9kg weight to the specified height for free fall. Mounted on wheels for convenient transportation and operation.
Standards
AS1289.6.3.2
Specification
TECHNICAL PARAMETERS
|
Power |
Stroke engine 3.5HP/ 127CC/3600RPM |
|
Drop height |
200mm |
|
Drop weight |
20kg |
|
Fuel |
Unleaded gasoline (or special grade) |
|
Mechanical transmission |
Flexible cable |
|
Rod |
Diameter 22mm, length 1m |
|
Cone |
Diameter 25.22mm, cone angle 90° |
|
Frequency |
30-40 times/minute |
|
Dimensions |
810×600×1680mm |
|
Weight |
80kg |
Features
● Easy to transport, flexible and simple to operate
● Features penetration rod fixing device that eliminates manual pre-fixing, ensuring rod verticality while saving time and effort
● Manual winch pre-lifting device with labor-saving pulley block ensures safe movement and transport, and simplifies rod addition or replacement
Accessories
16-T0013/B STANDARD DELIVERY
Anvil
Penetration rod, dia.16mm
DCP cone, 30°
Perth penetrometer tip
Spare flexible shaft
Spanner, 14mm
Manual rod extractor
Video
Documents
