Description of Product
The CTM-02 Automatic CBR Test Machine is specifically engineered for laboratory-based CBR testing to assess the load-bearing capacity of soil subgrades and base course materials (suitable for soil particles under 40mm). By incorporating servo motor control, the equipment ensures superior stability throughout the testing cycle. Furthermore, the integrated 7-inch touch screen simplifies the workflow by providing a clear display of all test parameters and real-time data. Please note that the CBR mould is an optional accessory and must be purchased separately.
Standards
- BS 1377, 1924
- EN 13286-47
- ASTM D1883
- AASHTO T193
Specification
TECHNICAL PARAMETERS
|
Maximum load |
50 KN |
|
Precision |
0.001KN |
|
Load speed |
1-5 mm/min |
|
Penetration rod |
End diameter 50 mm |
|
Test mould |
Dia. 152 mm x 177.8 mm |
|
Displacement sensor |
0-25mm, division: 0.01mm, linearity: 0.3% |
|
Dimensions |
34 x 45 x 88 cm |
|
Power |
220V,50Hz,500W |
|
Weight |
Net weight 88kg, gross weight 105kg |
Features
ASTM STANDARD
34-T0090 CBR mould complete with collar and perforated base plate. Plated steel, 6 in. (152.4mm) dia. x 7 in. (177.8mm) body height
34-T0091 Spacer disc with "T" handle. 515/16 in. dia. (150.8 mm) x 2.416 in. (61.4 mm) high
34-T0094 Annular surcharge weight, 2.27 kg
34-T0095 Slotted surcharge weight, 2.27 kg
34-T0098 Cutting edge
34-T0097 Solid CBR base
34-T0099 Straight edge. 3x30x300 mm
BRITISH STANDARD
- 34-T0090/B CBR mould body with base plate, made from plated steel threaded on both ends. 152mm ID x 127mm high, 50mm high collar.
- 34-T0090/BC CBR mould with three plugs collar
- 34-T0090/B6 "C" spanner. To mount and to dismount the collar from the mould body, 1kg
- 42-T0095/B Split surcharge weight (2 kg, 2.27 kg selectable)
EXPANSION (SWELL) TEST APPARATUS STANDARD
- 34-T0093 Dial gauge tripod
- 34-T0092/A Aluminium swell plate
- 34-T0092/B Brass swell plate
